MJ153D Auto-feed rip saw
點擊次數：2696 次

產品簡介及技術參數：

Widen tracked,Multiple sets of roller, feeding smoothly
Caterpillar pneumatic for dust cleaner
Four levels of the rebound devices more secure
Standard of pure copper wire motor power is strong


Super mesa widened chain plate	Four groups of protection operation safety

Auxiliary roller precision is higher Quenching rail longer life,Standard motor power is strong	0.10/2000mm Trimming precision

Technical Specification	Unit	MJ153D	MJ154D
Min. sawing length	mm	230	260
Sawing thickness	mm	10-85	10-125
Throat depth	mm	460	610
Saw blade diameter	mm	?250-305	?305-405
Spindle diameter	mm	?25.4	?25.4
Saw spindle speed	r/min	4000	3500
Main motor power	kW	7.5	11
Feeding motor power	kW	1.5	2.2
Feeding speed	m/min	12.5/16/19.5/24	6~25
Fixed table size	mm	1100×1600	1230×1750
Overall dimensions	mm	1800×1100×1356	2100×1400×1500
Net.weight	kg	980	1200
